APPLICABLE MATERIALS:

  • Solid wood

  • Jointed panel

  • MDF

OPTIONAL EQUIPMENTS:

  • Air blow sanding cleaning device.

  • Panel cleaning brush roller.

  • Vacuum suction conveyor table.

FEATURES:

  • Powered conveyor table elevation.

  • Automatic machine stop in case of power failure,

  • Automatic control for conveyor belt tracking.

  • This series of sander is ideal for continuous heavy-duty sanding.

  • Ideally suited for finer finishing effects for high production demands.

  • The conveyor table is firmly supported by four precision jack screws.

  • In case of insufficient air pressure, the machine can not be started thereby ensuring safety protection.

YU SHYANG is reputed for their wide belt sanding technology. We offer a large selection of sanders which are widely used in furniture, cabinetmaking and other wood product manufacturing.

Our commitment to upgrading sanding technology is backed by our experienced technicians, R&D team, modern manufacturing facility and rigorous quality control policy. We are dedicated to bringing you the finest sanders at a reasonable price with excellent performance. Your full satisfaction is our most important concern. We spend every possible effort to design and manufacture the sanders to make your sanding work productive and smooth. For more details about “YU SHYANG” quality sanders, please contact us or your local authorized distributor.

OUTSANTING RELIABILITY AND ACCURACY FROM YU SHYANG’S HEAVY-DUTY WIDE BELT SANDER SERIES

This series features excellent rigidity and precise construction to ensure a lifetime of accurate operations. Available in a choice of one, two or three head configurations and width capacities from 600 mm. to 1,300 mm., YU SHYANG’s heavy-duty wide belt sander series offer the right machine for the right requirement. Designed with maximum efficiency in mind, this series will deliver maximum output with the greatest of operational ease. The many fine features ensure increased production output with excellent finished quality.

MICRO-COMPUTER CONTROLLED THICKNESS SETTING



The conveyer table elevation can be accurately controlled by micro-computer with digital display of thickness value. The desired thickness can be preset for convenient operation.

01

SANDING BELT OSCILLATION CONTROLLED BY PHOTOCELL SENSOR



The machine employs photocell sensors to control the belt oscillation motions-without any dust entering problems. Oscillating sanding not only ensures excellent surface quality, but also extends service life of the belt. In case of insufficient air pressure, sanding belt not mounted, or sanding belt not properly tensioned, the machine stops automatically.

02

RP TYPE SANDING HEAD



This series of machines provides single, two and three head configurations to choose from. Also, a choice of contact drum or platen head is available. For mass production, a multi-head configuration is suggested.

03

BODY ACTIVATED EMERGENCY STOP BAR



This emergency stop bar is equipped at the infeed end. Once it is touched, the conveyor table will lower automatically for safety protection for the operator and the machine.

04

SYNCHRONIZED MICROMETRIC ADJUSTMENT FOR PRESSURE PLATE



The device permits a synchronized elevation for pressure plate, ensuring high accuracy adjustment.

05

PANEL CLEANING BRUSH ROLLER (OPTIONAL)



The panel cleaning brush roller is provided at the outfeed end of the conveyor belt for workpiece dust removal. A dust hood for the panel cleaning brush facilitates dust collection

06

AIR BLOWING SANDING BELT CLEANING DEVICE (OPTIONAL)



Effective cleaning of the sanding belt is provided by an oscillating air blower located over the idler roller.

07
